Description
Butt welded forged steel Y type strainer is a small device which is applied to remove the small amount of solid particles in fluid and keep the equipment running smoothly. When the fluid flows into filter cartridge, the impurities are blocked by the filter mesh in the cartridge and cleaned fluid flows out of strainer. It helps protect accessories (compressor, pump, display instrument and other devices) on pipeline system from wear and blocking in order to keep the medium transmission pipeline system work smoothly.
Application of Butt Welded Strainer
Butt welded forged steel Y type strainer is an essential device installed in medium transmission pipeline system. It is used to remove bigger solid particles in fluid (such as iron rust and sand grain in the sewage). This Y strainer, as filtration equipment, is widely applied in tap water, sewage, construction, petroleum, chemical, food, medicine, textile, electric power, shipbuilding, metallurgy, and energy pipeline systems.
Features
1. Butt welded forged steel Y type strainer features high filtration precision and dirt carrying ability.
2. Cleaning and mounting of this butt welded strainer are very easy and convenient. When cleaning the strainer, you only need to take out and clean the dismountable strainer cartridge.
3. All our products have passed API6D and CE certification.
4. Filter mesh is made of thickened stainless steel plate, which ensures its long serve life.
5. Valve body adopts precision casting technique.
6. Two times shot blasting processing assures exquisite appearance of this forged steel Y type strainer.
7. 18-month warranty and lifelong technology service are provided for all our products.
8. We can customize butt welded strainer according to your requirement.
Connection Types of Y Strainers
1. Flange Connection (GL41H/SLVY Hand Brush Type/YSTFH Rod Telescopic Flange Connection)
2. Screwed Connection (GL11 Threaded Connection)
3. Butt Welding Connection
How to Purchase Butt Welded Forged Steel Y Type Strainer
1. If you have any special request when purchasing our products, please indicate.
2. If you have already selected the proper model, you can place order directly.
3. If you are not sure about which model is suitable, please offer the following information including product material, nominal pressure, applicable medium, operating temperature and connection type, and we will give you the best suggestion.
4. If the working place is very important or working environment is complicated, it would be better to offer construction design drawing and our experts will design the most proper strainer for you.
Main Parts and Materials of Butt Welded Forged Steel Y Type Strainer
|
No.
|
Part Name
|
Carbon Steel
|
Stainless Steel
|
|
1
|
Body
|
A105
|
F304
|
F316
|
F316L
|
|
2
|
Cover
|
A105
|
F304
|
F316
|
F316L
|
|
3
|
Net
|
SS304
|
SS304
|
SS316L
|
SS316L
|
|
4
|
Filler
|
A105
|
SS304
|
SS316L
|
SS316L
|
|
5
|
Gasket
|
PTFE, Graphite
|
|
6
|
Stud Bolt
|
A193-B7
|
A193-B8
|
Classification of Butt Welded Strainer
1. SY Water Strainer
2. QG Steam Strainer
3. YQ Filter
Attentions When Purchasing Butt Welded Forged Steel Y Type Strainer
1. Generally, entrance and exit diameter of strainer should not be smaller than the entrance diameter of the supporting pump, and agree with the diameter of entrance pipeline.
2. Pressure rating of this butt welded strainer is determined by the maximum pressure of filtration pipeline.
3. When choosing mesh size, you should consider the diameter of the impurity.
4. Material of this Y strainer is similar with pipeline it connects. You can choose casting iron, carbon steel, low alloy steel and stainless steel Y filters considering your different serving conditions.
5. Please consider the resistance loss of the strainer.
Wenzhou Kerui Valve Industry Co., LTD is a professional manufacturer and supplier of various valves and Y strainers in China. Our main products cover ball valves, gate valves, globe valves, check valves and butt welded strainers. Our butt welded forged steel Y type strainers are widely applied in tap water, sewage, construction, petroleum, chemical, food, medicine, textile, electric power, shipbuilding, metallurgy, and energy pipeline systems.
